Intel Core i7-1355U, 10C (2P + 8E)/12T, P-core 1.7/5.0GHz, E-core 1.2/3.7GHz, 12MB, 8GB DDR4-3200 + 8GB SO-DIMM DDR4-3200, 512GB SSD M.2 2242 PCIe 4.0x4 NVMe Opal 2.0, 14" WUXGA (1920x1200) IPS 300nits Anti-glare 45% NTSC, Intel Iris Xe Graphics, Wi-Fi 6 11ax 2x2 + BT5.1, FHD 1080p + IR Hybrid with Privacy Shutter, Windows 11 Pro

Design
Housing material	Aluminium
Form factor	Clamshell
Colour name	Graphite black
Product colour	Graphite, Black
Product type	Laptop

Display
Contrast ratio (typical)	800:1
Maximum refresh rate	60 Hz
RGB colour space	NTSC
Colour gamut	45%
Display brightness	300 cd/m²
Anti-glare screen	Yes
LED backlight	Yes
Native aspect ratio	16:10
Panel type	IPS
HD type	WUXGA
Touchscreen	No
Display resolution	1920 x 1200 pixels
Display diagonal	35.6 cm (14")

Processor
Motherboard chipset	Intel SoC
Processor cache type	Smart Cache
Processor cache	12 MB
Processor cores	10
Performance cores	2
Efficient cores	8
Performance-core Max Turbo Frequency	5 GHz
Efficient-core Max Turbo Frequency	3.7 GHz
Processor boost frequency	5 GHz
Efficient-core boost frequency	3.7 GHz
Processor model	i7-1355U
Processor generation	13th gen Intel® Core™ i7
Processor family	Intel® Core™ i7
Processor manufacturer	Intel

Memory
Memory channels	Dual-channel
Maximum internal memory	40 GB
Memory slots	1x SO-DIMM
Memory layout (slots x size)	1 x 8 GB
Memory clock speed	3200 MHz
Memory form factor	On-board + SO-DIMM
Internal memory type	DDR4-SDRAM
Internal memory	16 GB

Storage
Card reader integrated	No
Optical drive type	No
SSD form factor	M.2
SSD interface	PCI Express 4.0
NVMe	Yes
SSD capacity	512 GB
Number of SSDs installed	1
Total SSDs capacity	512 GB
Storage media	SSD
Total storage capacity	512 GB

Graphics
On-board graphics card model	Intel Iris Xe Graphics
On-board graphics card family	Intel Iris Xe Graphics
On-board GPU manufacturer	Intel
Discrete graphics card model	Not available
Discrete graphics card	No
On-board graphics card	Yes

Audio
Number of microphones	2
Built-in microphone	Yes
Speaker power	2 W
Number of built-in speakers	2
Audio system	Dolby Atmos
Audio chip	Synaptic CX11880

Camera
Privacy type	Privacy shutter
Privacy camera	Yes
Infrared (IR) camera	Yes
Front camera resolution	1920 x 1080 pixels
Front camera HD type	Full HD
Front camera	Yes

Network
WWAN	Not installed
Near Field Communication (NFC)	No
Bluetooth version	5.1
Bluetooth	Yes
Ethernet LAN data rates	1000,100 Mbit/s
Ethernet LAN	Yes
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Mobile network connection	No

Ports & interfaces
USB Sleep-and-Charge ports	1
USB Sleep-and-Charge	Yes
USB Power Delivery	Yes
USB Type-C DisplayPort Alternate Mode	Yes
Combo headphone/mic port	Yes
Thunderbolt 4 ports quantity	1
Intel® Thunderbolt 4	Yes
HDMI version	2.1
HDMI ports quantity	1
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
USB 2.0 ports quantity	1

Keyboard
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	UK English
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav

Software
Operating system language	English
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro

Battery
Fast charging	Yes
Battery capacity	57 Wh
Battery technology	Lithium Polymer (LiPo)

Power
AC adapter input voltage	100 - 240 V
AC adapter frequency	50/60 Hz
AC adapter power	65 W

Security
Password protection type	BIOS, Power on, Supervisor, SSD
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Windows Hello	Yes
Fingerprint reader	Yes
Smart card reader	No
Cable lock slot type	Kensington
Cable lock slot	Yes

Operational conditions
Maximum shipping altitude	3048 m
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	8 - 95%
Storage temperature (T-T)	5 - 43 °C
Operating temperature (T-T)	5 - 35 °C

Certificates
Certification	MIL-STD-810HFSC certified package
Compliance certificates	RoHS

Sustainability
Sustainability certificates	TCO, ENERGY STAR, EPEAT Gold, ErP

Weight & dimensions
Height	18 mm
Depth	219.3 mm
Width	313 mm
Weight	1.53 kg

General
Product Family	ThinkPad
Product Series	E
