Meshify strikes an aggressive pose in the Fractal Design lineup with unparalleled cooling performance and a defiant new look. Like black diamond facets, the angular asymmetry of the Meshify C – TG carves a space uniquely its own as a new force in high-airflow design. Offering a lighter tint than the Meshify C, the Meshify C – TG gives users a clear view into the inside of their case.
An open ATX layout with intelligent space utilization creates an unrestricted airflow path from the mesh front intakes directly through key components to exhaust, ensuring heat is never an issue. The Meshify C – TG has a remarkably compact footprint with the high-end component support of a larger tower, and with seven fan mounts and multi-radiator liquid cooling capability, it has the cooling capacity to match.
When performance is top priority and compromise is not an option, Meshify has you covered in style.
Design | |
---|---|
Maximum PSU length | 17.5 cm |
Maximum graphics card length | 31.5 cm |
Maximum CPU cooler height | 17.2 cm |
Anti-dust filter | Yes |
Side window | Yes |
Number of expansion slots | 7 |
Number of 2.5" bays | 3 |
Number of 3.5" bays | 2 |
Supported motherboard form factors | ATX, ITX, micro ATX |
Product colour | Black, Transparent |
Material | Glass |
Type | PC |
Form factor | Midi Tower |
Power supply | |
---|---|
Supported power supply form factors | ATX |
Power supply included | No |
Ports & interfaces | |
---|---|
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
Cooling | |
---|---|
Top radiator sizes supported | 120,240 mm |
Rear radiator sizes supported | 120 mm |
Front radiator sizes supported | 120,240,360 mm |
Bottom fans diameters supported | 120 mm |
Number of bottom fans supported (max) | 1 |
Top fans diameters supported | 120,140 mm |
Number of top fans supported (max) | 2 |
Rear fans diameters supported | 120 mm |
Number of rear fans supported (max) | 1 |
Rear fans installed | 1x 120 mm |
Front fans diameters supported | 120,140 mm |
Number of front fans supported (max) | 3 |
Front fans installed | 1x 120 mm |
Storage | |
---|---|
Supported HDD sizes | 2.5,3.5" |
Packaging content | |
---|---|
Manual | Yes |
Weight & dimensions | |
---|---|
Material thickness | 3 mm |
Weight | 6.45 kg |
Height | 440 mm |
Depth | 395 mm |
Width | 212 mm |
Packaging data | |
---|---|
Package weight | 7.81 kg |
Package height | 493 mm |
Package depth | 542 mm |
Package width | 305 mm |
Logistics data | |
---|---|
Harmonized System (HS) code | 84733080 |
