Archer GX90 provides 3 distinct bands with combined speed up to warp 6579 Mbps. A fully featured Gaming Band is equiped with 4T4R and HE160 technology, offering all your gaming rigs at top speed 4804 Mbps and preventing interference from other devices. More connected devices mean more fun without dragging down performance. Revolutionary OFDMA is introduced to improve average throughput by 4 x and cut the latency. Take advantage of incredibly low latency to demolish your enemies with your team crew together. Game accelerator automatically detects and optimizes gaming streams, to ensure your gaming stays immersive and keep your network as fast as your reaction speed.△ GAME STATISTICS shows the real-time latency, game duration and system utilization at a glance in a refreshed dashboard with fine-tuned UI elements, puts total control at your fingertips. DFS expands available channel automatically, get on the more vacant lane and boost the game. Tri-band structure provides a 4.8 gbps game band exclusive for your gaming rigs and brings pure immersion. Detect and optimize gaming streams, to ensure your gaming stays immersive. Real-time latency, game duration and network resource allocation in a glance with fine-tuned ui. Keep your accounts and documents safe with homecare security system. 8 antennas, beamforming, high-power fem, 4t4r combine to deliver wifi coverage up to a 4-bedroom house. Unleash the potential of your next-level bandwidth network with a 2.5 gbps wan/lan port. 1.5 ghz quad-core cpu ensure your network performance always at peak run. Set it up in minutes with the powerful tether app.
WAN connection | |
---|---|
WAN connection type | RJ-45 |
3G/4G USB modem compatibility | No |
SIM card slot | No |
DSL WAN | No |
Ethernet WAN | Yes |
Wireless LAN features | |
---|---|
WLAN data transfer rate (third band) | 574 Mbit/s |
WLAN data transfer rate (second band) | 1201 Mbit/s |
WLAN data transfer rate (first band) | 4804 Mbit/s |
Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 5 (802.11ac), 802.11g |
WLAN data transfer rate (max) | 6600 Mbit/s |
Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 5 GHz) |
Network | |
---|---|
VPN server | OpenVPN, PPTP |
Number of guest networks (2.4 GHz) | 1 |
Number of guest networks (5 GHz) | 1 |
Port forwarding | Yes |
Port triggering | Yes |
Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
Cabling technology | 10/100/1000Base-T(X) |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ethernet LAN interface type | Gigabit Ethernet |
Ethernet LAN | Yes |
Mobile network | |
---|---|
3G | No |
4G | No |
Ports & interfaces | |
---|---|
DC-in jack | Yes |
Memory card slot(s) | No |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
USB 2.0 ports quantity | 1 |
USB port | Yes |
Ethernet LAN (RJ-45) ports | 5 |
Management features | |
---|---|
WPS push button | Yes |
Reset button | Yes |
Security | |
---|---|
DMZ support | Yes |
Parental control | Yes |
Stateful Packet Inspection (SPI) | Yes |
Access Control List (ACL) | Yes |
Firewall | Yes |
Protocols | |
---|---|
Supported network protocols | IPv4, IPv6 |
Universal Plug and Play (UPnP) | Yes |
DHCP server | Yes |
DHCP client | Yes |
Design | |
---|---|
Country of origin | Malaysia |
On/off switch | Yes |
LED indicators | LAN, Power, WLAN |
Indication light | Yes |
Product colour | Black |
Product type | Tabletop router |
Packaging content | |
---|---|
Packaging content | 1 x TP-Link Archer AX6600 Tri-Band Gigabit and 2.5G Gaming Router, Black |
Manual | Yes |
AC adapter included | Yes |
Cables included | LAN (RJ-45) |
Antenna | |
---|---|
Detachable antenna(s) | Yes |
Antennas quantity | 4 |
Antenna design | External |
Features | |
---|---|
Certification | FCC, CE, RoHS |
Processor cores | 4 |
Processor frequency | 1500 MHz |
Built-in processor | Yes |
Power | |
---|---|
Output current | 5 A |
Output voltage | 12 V |
Power source type | DC |
Operational conditions | |
---|---|
Operating temperature (T-T) | 0 - 40 °C |
Operating relative humidity (H-H) | 10 - 90% |
Storage temperature (T-T) | -40 - 70 °C |
Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions | |
---|---|
Width | 212 mm |
Depth | 212 mm |
Height | 51.8 mm |
Packaging data | |
---|---|
Package weight | 580 g |
Package height | 38 mm |
Package depth | 266 mm |
Package width | 124 mm |
Logistics data | |
---|---|
Harmonized System (HS) code | 85176990 |
Quantity per pack | 1 pc(s) |
