| Display |
| HDCP |
Yes |
| Display brightness (typical) |
300 cd/m² |
| Screen shape |
Flat |
| Dynamic contrast ratio marketing name |
Mega Infinity DCR |
| Display number of colours |
16.7 million colours |
| Native aspect ratio |
16:9 |
| Pixel density |
92.56 ppi |
| DDC/CI |
Yes |
| Colour gamut |
93% |
| Maximum refresh rate |
180 Hz |
| sRGB coverage (typical) |
126% |
| Adobe RGB coverage |
88% |
| HD type |
Full HD |
| Display technology |
LCD |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Horizontal scan range |
30 - 200 kHz |
| Vertical scan range |
48 - 180 Hz |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| Backlight type |
W-LED |
| Display resolution |
1920 x 1080 pixels |
| Response time |
1 ms |
| Display diagonal |
60.5 cm (23.8") |
| Contrast ratio (typical) |
1000:1 |
| Surface hardness |
3H |
| Response time (fast) |
0.5 ms |
| NTSC coverage (typical) |
113% |
| Touchscreen |
No |
| High Dynamic Range (HDR) supported |
Yes |
| Panel type |
IPS |
| High Dynamic Range (HDR) technology |
High Dynamic Range 10 (HDR10) |
| Display diagonal (metric) |
60.5 cm |
| Display sRGB |
Yes |
| Haze rate |
25% |
| LED backlight |
Yes |
| Colour gamut standard |
DCI-P3 |
| Anti-glare screen |
Yes |
| Audio |
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Performance |
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Mean time between failures (MTBF) |
50000 h |
| Built-in camera |
No |
| AMD FreeSync |
No |
| Compatible operating systems |
Mac OS X Windows 11/10 |
| NVIDIA G-SYNC |
No |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Component video sync |
Separate sync |
| Brand specific technologies |
Crosshair |
| Low input lag |
Yes |
| EasyRead mode |
Yes |
| Management features |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
21 |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian |
| Plug and Play |
Yes |
| Multimedia |
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| RMS rated power |
4 W |
| Built-in camera |
No |
| Design |
| Market positioning |
Gaming |
| Product colour |
White |
| Mean time between failures (MTBF) |
50000 h |
| Exterior finish type |
Textured |
| Camera |
| Built-in camera |
No |
| Ports & interfaces |
| Built-in USB hub |
No |
| Headphone out |
Yes |
| HDMI ports quantity |
2 |
| DisplayPorts quantity |
1 |
| HDCP |
Yes |
| HDMI |
Yes |
| HDMI version |
2.0 |
| DisplayPort version |
1.4 |
| HDCP version |
1.4/2.2 |
| Technical details |
| Height (without stand) |
325 mm |
| Depth (without stand) |
55 mm |
| Width (without stand) |
540 mm |
| Cable lock slot |
Yes |
| Mean time between failures (MTBF) |
50000 h |
| HDMI |
Yes |
| Product colour |
White |
| Picture enhancement |
SmartImage game |
| Recyclable packaging material |
100% |
| Regulatory Approvals |
CB, CE Mark, TUV/ISO9241-307, TUV-BAUART, EAC, EAEU RoHS, UKCA, EMF, FCC, ICES-003 |
| Compliance certificates |
RoHS |
| Compatible operating systems |
Mac OS X Windows 11/10 |
| Power supply type |
Internal |
| Weight (with stand) |
4.56 kg |
| Surface hardness |
3H |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Adaptive synchronisation |
Yes |
| Touchscreen |
No |
| Ergonomics |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| LED indicators |
Operation, Stand-by |
| Swivelling |
Yes |
| Swivel angle range |
-30 - 30° |
| Tilt angle range |
-5 - 20° |
| Height adjustment |
13 cm |
| Pivot |
Yes |
| On Screen Display (OSD) |
Yes |
| Pivot angle |
-90 - 90° |
| Number of OSD languages |
21 |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian |
| Plug and Play |
Yes |
| Height adjustment |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Power |
| Power supply type |
Internal |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
18.7 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency class (SDR) |
E |
| Energy efficiency class (HDR) |
F |
| Energy consumption (SDR) per 1000 hours |
18 kWh |
| Energy consumption (HDR) per 1000 hours |
22 kWh |
| Operational conditions |
| Non-operating altitude |
3658 - 12192 m |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating altitude |
0 - 3658 m |
| Weight & dimensions |
| Height (without stand) |
325 mm |
| Depth (without stand) |
55 mm |
| Width (without stand) |
540 mm |
| Width (with stand) |
540 mm |
| Depth (with stand) |
261 mm |
| Height (with stand) |
515 mm |
| Weight (with stand) |
4.56 kg |
| Weight (without stand) |
2.76 kg |
| Package width |
730 mm |
| Package depth |
188 mm |
| Package height |
420 mm |
| Package weight |
7.38 kg |
| Packaging data |
| Package width |
730 mm |
| Package depth |
188 mm |
| Package height |
420 mm |
| Package weight |
7.38 kg |
| Stand included |
Yes |
| Manual |
Yes |
| Cables included |
AC, DisplayPort, HDMI |
| Packaging content |
| Stand included |
Yes |
| Manual |
Yes |
| Cables included |
AC, DisplayPort, HDMI |
| Indication |
| LED indicators |
Operation, Stand-by |
| Other features |
| Compatible operating systems |
Mac OS X Windows 11/10 |
| Mean time between failures (MTBF) |
50000 h |
| Picture enhancement |
SmartImage game |
| Recyclable packaging material |
100% |
| Regulatory Approvals |
CB, CE Mark, TUV/ISO9241-307, TUV-BAUART, EAC, EAEU RoHS, UKCA, EMF, FCC, ICES-003 |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Adaptive synchronisation |
Yes |
| Exterior finish type |
Textured |
| Brand specific technologies |
Crosshair |
| Low input lag |
Yes |
| Compliance certificates |
RoHS |
| Height (without stand) |
325 mm |
| Depth (without stand) |
55 mm |
| Width (without stand) |
540 mm |
| HDMI |
Yes |
| Surface hardness |
3H |
| Power supply type |
Internal |
| Manual |
Yes |
| Touchscreen |
No |
| Recycling data |
| Post-consumer recycled plastic |
35% |
