Intel Core i5-1240P, 12C (4P + 8E)/16T, P-core 1.7/4.4GHz, E-core 1.2/3.3GHz, 12MB, 16GB LPDDR5-5200, 256GB SSD M.2 2242 PCIe 4.0x4 NVMe Opal2, 13" 2K (2160x1350) IPS 450nits Anti-glare, Intel Iris Xe Graphics, Intel AX211 Wi-Fi 6E 2x2 + BT5.1, Discrete IR & FHD 1080p MIPI with Privacy Shutter, Computer Vision, Windows 11 Pro 64

Raising the bar for laptops everywhere
Our lightest ever ThinkPad, the ThinkPad X1 Nano Gen 2 weighs from just 970g but packs a punch. With up to 12th Gen Intel® Core™ vPro® processors, it has optional 5G connectivity and comes with advanced biometric and AI-based security, plus smart battery-saving features. Just as impressive is the truly stunning viewing and immersive audio experience it gives you.

Performs like a dream, everywhere
Powered by up to 12th Gen Intel® Core™ i7 vPro® processors and up to 32GB of memory, the ThinkPad X1 Nano zips through everything, effortlessly. Designed with on-the-go performance and responsiveness in mind, this 13" laptop comes with two USB-C Thunderbolt™ 4 ports, so you can enjoy lightning-fast data transfers and the flexibility of multiple hi-res displays.

A sight like no other
With the ThinkPad X1 Nano laptop, the first thing that catches the eye is the sumptuous 13" Dolby Vision™ 2K display. Available with or without a touchscreen option, it delivers larger-than-life views thanks to a 16:10 aspect ratio. And with 100% sRGB, the 2160 x 1350 resolution panel gives you superb clarity and stunning colour accuracy.

A sound like no other
Whether for work or play, the ThinkPad X1 Nano’s Dolby Atmos® Speaker System will take your listening to new heights with its amazing, immersive sound. Dolby Voice®- enabled, it actively suppresses background noise to give you the best audio/video conferencing experience. And with 360-degree, quad-array far-field mics, you’ll be heard loud and clear on every call.

So light, yet full of bright features
The smart, ultraportable the ThinkPad X1 Nano weighs from just 0.97kg/2.14lbs. Yet, thanks to Computer Vision and an FHD MIPI hybrid infrared camera (both optional), it can auto dim the screen when it’s not in use and alert you if someone’s watching over your shoulder. It even has your digital wellness in mind, by reminding you to take regular breaks and avoid poor posture.

Enhanced security, from the inside out
The ThinkPad X1 Nano ThinkShield security features include advanced AI and biometric technology. User-presence sensors will lock your PC when you step away and there’s a privacy shutter to physically close the webcam. Data is encrypted by the discrete Trusted Platform Module (dTPM) and you can log in securely with just your fingerprint.

Tap into the future, from anywhere
Your ThinkPad X1 Nano laptop keeps you in the loop, on the go. The 5G (Sub-6GHz) option offers a smartphone-like experience in an always-connected PC. Super-fast WiFi 6E cuts out any buffering and lagging, even on the busiest public platforms. And with the optional 4G / 5G service, you can stream videos seamlessly and enjoy faster, more secure network access.

Durability is our middle name
Striking the perfect balance of reliability and durability, ThinkPad laptops are tested against 12 military-grade standards and more than 200 quality checks to ensure they run in extreme conditions. From the Arctic wilderness to desert dust storms, these tests cover severe environmental variables including temperature, pressure, dust, humidity, and vibration testing.

Design
Housing material	Carbon fibre, Magnesium
Form factor	Clamshell
Colour name	Black, Paint
Product colour	Black
Product type	Laptop

Display
Contrast ratio (typical)	1000:1
RGB colour space	sRGB
Colour gamut	100%
Display brightness	450 cd/m²
Anti-glare screen	Yes
LED backlight	Yes
Native aspect ratio	16:10
Panel type	IPS
HD type	2K
Touchscreen	No
Display resolution	2160 x 1350 pixels
Display diagonal	33 cm (13")

Processor
Configurable TDP-down	20 W
Motherboard chipset	Intel SoC
Processor cache	12 MB
Processor cores	12
Processor boost frequency	4.4 GHz
Processor frequency	1.7 GHz
Processor model	i5-1240P
Processor generation	12th gen Intel® Core™ i5
Processor family	Intel® Core™ i5
Processor manufacturer	Intel

Memory
Maximum internal memory	16 GB
Memory clock speed	5200 MHz
Memory form factor	On-board
Internal memory type	LPDDR5-SDRAM
Internal memory	16 GB

Storage
Card reader integrated	No
Optical drive type	No
SSD form factor	M.2
SSD interface	NVMe, PCI Express 4.0
NVMe	Yes
SSD capacity	256 GB
Number of SSDs installed	1
Total SSDs capacity	256 GB
Storage media	SSD
Total storage capacity	256 GB

Graphics
On-board graphics card model	Intel Iris Xe Graphics
On-board graphics card family	Intel Iris Xe Graphics
On-board GPU manufacturer	Intel
Discrete graphics card model	Not available
Discrete graphics card	No
On-board graphics card	Yes

Audio
Number of microphones	4
Built-in microphone	Yes
Number of built-in speakers	4
Audio system	Dolby Atmos
Audio chip	Realtek ALC3306

Camera
Privacy type	Privacy shutter
Privacy camera	Yes
Infrared (IR) camera	Yes
Front camera resolution	1920 x 1080 pixels
Front camera HD type	Full HD
Front camera	Yes

Network
WWAN	Installed
Near Field Communication (NFC)	No
Bluetooth version	5.2
Bluetooth	Yes
Ethernet LAN	No
WLAN controller model	Intel Wi-Fi 6E AX211
WLAN controller manufacturer	Intel
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6E (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Mobile network connection	No

Ports & interfaces
USB Power Delivery	Yes
USB Type-C DisplayPort Alternate Mode	Yes
Combo headphone/mic port	Yes
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes

Keyboard
Spill-resistant keyboard	Yes
Keyboard backlit	Yes
Numeric keypad	No
Keyboard language	UK English
Keyboard layout	QWERTY
Pointing device	ThinkPad UltraNav

Software
Bundled software	Intel Connectivity Performance Suite
Operating system language	English
Operating system architecture	64-bit
Operating system installed	Windows 11 Pro

Processor special features
Intel Flex Memory Access	Yes
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Execute Disable Bit	Yes
CPU configuration (max)	1
Embedded options available	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes

Battery
Battery capacity	49.5 Wh
Battery technology	Lithium Polymer (LiPo)

Power
AC adapter input voltage	100 - 240 V
AC adapter frequency	50 - 60 Hz
AC adapter power	65 W

Security
Password protection type	BIOS, Power on, Supervisor
Password protection	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Fingerprint reader	Yes
Smart card reader	No
Cable lock slot type	Kensington
Cable lock slot	Yes

Operational conditions
Storage relative humidity (H-H)	5 - 95%
Operating relative humidity (H-H)	8 - 95%
Storage temperature (T-T)	5 - 43 °C
Operating temperature (T-T)	5 - 35 °C

Certificates
Compliance certificates	RoHS

Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, ErP, TCO

Weight & dimensions
Height	14.8 mm
Depth	208.1 mm
Width	293.3 mm
Weight	966.5 g

General
Product Family	ThinkPad
Product Series	X

Logistics data
Harmonized System (HS) code	84713000
