Wireless Feature |
Common feature |
3GPP Release16 |
Yes |
|
|
|
5G NR SA&NSA (Support:5G NR CA, 5G NR + LTE EN-DC) LTE FDD/TDD UMTS |
Yes |
|
|
|
Modulation: Sub6G DL: 256QAM UL: 256QAM LTE DL: 256QAM UL: 256QAM |
Yes |
|
|
|
Bandwidth of Sub6G:40MHz, 60MHz, 80MHz, 100MHz, 50MHz, 90MHz |
Optional |
Bandwidth of different frequency bands are different. |
|
|
Network Slicling |
Yes |
|
|
|
Transmitter power for wireless 26dBm for N78, 23dBm for other bands |
Yes |
|
|
Bands |
5G: N1/3/7/8/20/28/38/40/75/77/78 |
Yes |
|
|
|
4G: B1/3/7/8/20/28/32/38/40/42/43
|
Yes |
|
|
|
3G: B1/8
|
Yes |
|
|
|
4MIMO 5G Sub6:N1/3/7/38/40/75/77/78 supports 4*4MIMO; LTE: B1/3/7 supports 4MIMO |
Yes |
|
|
Speed |
5G ENDC LTE FDD + Sub6G DL 2.716Gb/s UL 280Mb/s
|
Yes |
DL 2.716 Gb/s (10layer LTE 20M 256QAM + 120M NR 256QAM 4*4MIMO 75% DL) UL 280Mb/s (2CA LTE 20M 256QAM + 100M NR 256QAM 25% UL) |
|
|
5G ENDC LTE TDD + Sub6G DL 3.03Gb/s UL 250Mb/s
|
Yes |
DL 3.03Gb/s (16layer LTE 20M 256QAM + 100M NR 256QAM 4*4MIMO 75% DL) UL 250Mb/s (2CA LTE 20M 256QAM 75%+ 100M NR 256QAM 25% UL) |
|
|
5G SA (5G Sub6G -TDD) DL: 1.716Gb/s UL: 160Mb/s
|
Yes |
DL peak rates requires: 120MHz + 256QAM + 4MIMO 75% DL duty cycle; UL peak rates requires: 100MHz + 256QAM + 2MIMO 25% duty cycle. This is theoretical Max Rate on this device platform. The different Hardware configuration and requirement will result different rate |
|
|
LTE FDD(DL Category19, UL Category18): DL 1.6Gb/s UL 200Mbps
LTE TDD DL 1.12Gb/s UL 40Mb/s
|
Yes |
FDD peak rates require DL: 256QAM + 5CA (16 layers); UL: 256QAM + 2CA intra-bands and inter-bands TDD peak rates require DL: 256QAM + 5CA (16 layers); UL: 256QAM + 2CA intra-bands and inter-bands. And TDD frame config 2 (DL/UL ratio 7:2) This is theoretical Max Rate on this device platform. The different Hardware configuration and requirement will result different rate |
|
|
WCDMA CS: UL 64kbps/DL 64kbps WCDMA PS: UL 384kbps/DL 384kbps
HSDPA: DL 14.4Mb/s(Category 10) DL 21Mb/s(Category 14) DL 42Mb/s(Category 24) HSUPA: UL 5.76Mb/s(Category 6)
|
Yes |
|
|
WiFi |
WiFi6, 802.11b/g/n/a/ac/ax |
Yes |
|
|
|
2*2MIMO for both 2.4G and 5G |
Yes |
|
|
|
2.4GHz 2MIMO 688Mbps 5GHz 2MIMO 2.882Gbps The totoal theoretical speed can up to AX3600 |
Yes |
|
|
|
Bandwidth: 2.4G: 20M/40M 5G: 20M/40M/80M/160M |
Yes |
|
|
|
Access number: up to 64 |
Yes |
|
|
|
Modulation:up to 4K-QAM |
Yes |
|
|
Antenna
|
700~960MHz: 1~1.5dbi 1450~2700MHz: 2.5~3dbi 3300~4200MHz: 5dBi |
Yes |
|
|
|
WiFi Gain: 2.4GHz 1.5dbi;5GHz: 2.5dbi
|
Yes |
|
|
|
Internal antenna for both all bands and WiFi |
Yes |
Device have built-in antennas with 10 LTE/NR omni-antennas and 2 WIFI omni-antennas , and no directional antennas inside the case. |
Hardware |
Arkwork |
Dimensions:182mm*124mm*70mm |
Yes |
|
|
Weight |
about 517g |
Yes |
|
|
Maximum power consumption |
about 15w
|
Yes |
|
|
Interface |
RJ45:2 2xGE |
Yes |
|
|
|
RJ11:1 |
Yes |
|
|
|
Usb:1 |
Yes |
|
|
|
SIM slot: 4FF |
Yes |
|
|
|
Reset button |
Yes |
|
|
|
WPS button |
Yes |
|
|
LED |
Power: White |
Yes |
|
|
|
WiFi: White |
Yes |
|
|
|
Network: White/Blue/Red |
Yes |
|
|
|
Singal Strength:White |
Yes |
|
|
|
LAN: RJ45 port's LED |
Yes |
|
|
|
Screen:NA |
No |
|
Ingress Protection rating |
|
IP30 |
Yes |
|
Environment specifications |
Operating temperature |
-20 to 55° C |
Yes |
|
|
Storage temperature |
-40 to 70° C |
Yes |
|
|
Humidity |
5% to 95%
|
Yes |
|
Certification |
|
CE,WEEE,ROHS,WiFi |
Yes |
|
Package contents |
|
AC Adapter:12V/1.5A |
Yes |
|
|
|
Ethernet cable |
Yes |
|
|
|
Quick Start Guide |
Yes |
|
|
|
EAN can be customized |
Yes |
|
|
|
TAC can be customized |
Yes |
|
Software |
Device Mode |
Automatically mode (wireless or wire auto switch) |
Yes |
|
|
|
Hybird mode (wireless and wired are used at same time) |
Yes |
|
|
|
Wireless mode |
Yes |
|
|
|
Bridge mode |
Yes |
|
|
|
Cable Broadband Mode |
Yes |
|
|
IP networking |
IPv4/IPv6 dual stack (NDP IPv6) |
Yes |
|
|
|
DHCP server |
Yes |
|
|
|
Virtual Private Network (VPN) : |
Yes |
|
|
|
pass-through(L2TP/PPTP/IPSec) |
Yes |
|
|
|
L2TP client |
Yes |
|
|
|
PPTP client |
Yes |
|
|
|
NAT/NAPT |
Yes |
|
|
|
Sip ALG |
Yes |
|
|
Firewall |
Port Forwarding |
Yes |
|
|
|
Port Filtering |
Yes |
|
|
|
Port Mapping |
Yes |
|
|
|
Domain Filtering |
Yes |
|
|
|
Upnp |
Yes |
|
|
|
DMZ |
Yes |
|
|
|
MAC address filtering |
Yes |
|
|
WiFi |
WiFi Switch |
Yes |
|
|
|
Bandsteering |
Yes |
|
|
|
Security mode: OPEN, WPA-PSK/WPA2-PSK, WPA2-PSK/WPA3-PSK,WPA2-PSK, WPA3-PSK |
Yes |
|
|
|
WiFi Broadcast
|
Yes |
|
|
|
Auto channel selection |
Yes |
|
|
|
WPS |
Yes |
|
|
|
GuestSSID support |
Yes |
|
|
|
WiFi Sleep Mode |
Yes |
|
|
Voice |
CSFB/VOIP/VOLTE |
Yes |
|
|
Device Managemnt |
Connected device Management |
Yes |
|
|
|
SMS |
Yes |
|
|
|
PIN/PUK management |
Yes |
|
|
|
APN management |
Yes |
|
|
|
lock band |
Yes |
|
|
|
Upgrade: FOTA |
Yes |
|
|
|
Device can FOTA access on bridge mode |
Yes |
|
|
Special Feature |
Preferred Position:Can help user to find a good position |
Yes |
|
|
|
NFC:Andriod phone touch can access the Router WiFi |
No |
|
|
|
Device Diagnosis will list all device running key status and give fix solution |
Yes |
|
